Big one X

Big one X

Big one Big one S Big one X

Big one X - 2024

E-scooter for demanding, moderate and hilly terrain. In the version with a 7 kW motor (peak power 1s to 13 kW)

is one of our most powerful machines. With a peak power of up to 13 kW, it is literally an asphalt breaker. Riding this machine will get your adrenaline pumping. The Model X has an improved battery with a "smart" BMS that communicates with the control unit. The battery also includes temperature and humidity sensors. It can handle any terrain, even steep climbs. Even the cold is no obstacle for the Xko, on the contrary, riding in the snow will bring you a lot of fun. For its high performance not approved for use on the road. If you really want to experience something special, take the BIG One X off the road and explore the uncharted corners of your region.

Batteries

Samsung 30Q 33 Ah IP53

Engine

250W - 7 kW

Getting there

Ø 75 km

Speed

70 km/h *

Charging

3 A (stronger can be purchased)

Destination

medium - heavy terrain

Frame

steel/dural

Fork/damper

air 120mm/no back. dampers

Brakes/discs

MAGURA MT5e / 203 mm

Wheel size

26" / 20"

Dimensions

h x w x d - 118 x 75 x 201 cm

Weight

55 kg
HUGO E-bikes can be purchased in a version for use on public roads (250W power, max. speed 25km/hour) and in a version for use off public roads (1-10kW).

Equipment

Big one X

BRZDY

The Big One X is fitted with MAGURA MT5e brakes as standard, with a micro switch on each brake lever to engage the regenerative braking and disconnect the engine in an emergency.

DISPLAY

The centre display of the BAFANG 850C is highly legible even on a sunny day. It is waterproof and includes a USB connector for charging a mobile phone or other accessories. Easy map switching on the left handle is ensured by large enough buttons that can be operated even with gloves. The display shows basic speedometer functions such as: current speed, ODO, TRIP, total time, battery status, current power, clock and much more.

LIGHTS

Front light LED PROPLAST 1000 Lumen white with one lens, rear red LED with brake light.

STAND

Fixed stand with adjustable leg length.

FORKS

Air fork with high quality gliders and the ability to adjust stiffness and rebound. Specially designed for HUGO Bike with 120mm travel.

THE CHARGER

The e-scooter comes with a 3 A charger as standard. You can also choose a faster 4 A or 10 A charger.

BLATHERS

The rear mudguard is self-supporting and has been specially designed to have a brake light mount at its end. There is a handle on the back for easy carrying of the whole machine, while the fender protects the rider's back from splashing water. The front mudguard combines design with practicality and is integrated into the frame so that it doesn't spoil the look of the machine and safely catches almost every drop.

WHEELS AND PLATES

26" front wheel on KENDA tyres with a thicker pattern. Rear wheel 20" (moto 16") also on KENDA tyres with the same tread pattern as the front tyre. Both tyres are CYKLO. The rear wheel can be fitted with a MOTO tyre (16").

MOTOR

Motor with 150 N.M of torque custom adapted for HUGO Bike by QS. max. power 7 kW and up to 13 kW at peak for 1 second. IP54 protection.

BATTERIES

Starting in 2023, we are putting a unique "smart" BMS in every battery of the S/X/S.E.N. model series. The control unit communicates with the BMS via a CAN bus data link through a program and the control unit adjusts the parameters itself to avoid overloading the battery or, conversely, the motor, thus extending the overall battery life and range. Battery blocks now include a temperature sensor and now also a humidity sensor, which can prevent battery destruction due to water ingress into the block. Battery 48 V, Samsung 30Q 33 Ah. IP53 protection.

SEAT

The hand-sewn saddle with a wide and comfortable seat cushion ensures maximum comfort even on longer trips. The saddle is very easy to remove without the use of mounting wrenches.

ROWS

The handlebar height is for a rider's height from 150 to 180 cm. If the rider is taller, it is necessary to order an increase of about 5 cm. The width of the handlebars is approx. 720 mm. The width can be freely adjusted.
Big one X
BRZDY

BRZDY

The Big One X is fitted with MAGURA MT5e brakes as standard, with a micro switch on each brake lever to engage the regenerative braking and disconnect the engine in an emergency.
DISPLAY

DISPLAY

The centre display of the BAFANG 850C is highly legible even on a sunny day. It is waterproof and includes a USB connector for charging a mobile phone or other accessories. Easy map switching on the left handle is ensured by large enough buttons that can be operated even with gloves. The display shows basic speedometer functions such as: current speed, ODO, TRIP, total time, battery status, current power, clock and much more.
LIGHTS

LIGHTS

Front light LED PROPLAST 1000 Lumen white with one lens, rear red LED with brake light.
STAND

STAND

Fixed stand with adjustable leg length.
FORKS

FORKS

Air fork with high quality gliders and the ability to adjust stiffness and rebound. Specially designed for HUGO Bike with 120mm travel.
THE CHARGER

THE CHARGER

The e-scooter comes with a 3 A charger as standard. You can also choose a faster 4 A or 10 A charger.
BLATHERS

BLATHERS

The rear mudguard is self-supporting and has been specially designed to have a brake light mount at its end. There is a handle on the back for easy carrying of the whole machine, while the fender protects the rider's back from splashing water. The front mudguard combines design with practicality and is integrated into the frame so that it doesn't spoil the look of the machine and safely catches almost every drop.
WHEELS AND PLATES

WHEELS AND PLATES

26" front wheel on KENDA tyres with a thicker pattern. Rear wheel 20" (moto 16") also on KENDA tyres with the same tread pattern as the front tyre. Both tyres are CYKLO. The rear wheel can be fitted with a MOTO tyre (16").
MOTOR

MOTOR

Motor with 150 N.M of torque custom adapted for HUGO Bike by QS. max. power 7 kW and up to 13 kW at peak for 1 second. IP54 protection.
BATTERIES

BATTERIES

Starting in 2023, we are putting a unique "smart" BMS in every battery of the S/X/S.E.N. model series. The control unit communicates with the BMS via a CAN bus data link through a program and the control unit adjusts the parameters itself to avoid overloading the battery or, conversely, the motor, thus extending the overall battery life and range. Battery blocks now include a temperature sensor and now also a humidity sensor, which can prevent battery destruction due to water ingress into the block. Battery 48 V, Samsung 30Q 33 Ah. IP53 protection.
SEAT

SEAT

The hand-sewn saddle with a wide and comfortable seat cushion ensures maximum comfort even on longer trips. The saddle is very easy to remove without the use of mounting wrenches.
ROWS

ROWS

The handlebar height is for a rider's height from 150 to 180 cm. If the rider is taller, it is necessary to order an increase of about 5 cm. The width of the handlebars is approx. 720 mm. The width can be freely adjusted.

Big one X

E-scooter for demanding, moderate and hilly terrain. In the version with a 7 kW motor (peak power 1s to 13 kW)
Basic price
124 793 CZK without VAT
151 000 including VAT

Big one X

Basic price
124 793 CZK without VAT
151 000 including VAT

Compare



58 V - 56 Ah/88 Ah/110 Ah
250W - 7 kW/10 kW
up to 300 km
25/45/85 km/h *
10 A/ 15 A
161157 CZK without VAT
Coming Soon
extreme terrain
h x w x d - 130 x 80 x 205 cm
MAGURA MTe5/ MT7e /203 mm
air. Upside down HD 200
18" (moto 14"). Individually: 20" (moto 16") and 16" (moto 12")
dural
20 Ah IP53
250W - 1 kW
Ø 70 km
25 km/h *
3 A (stronger can be purchased)
53636 CZK without VAT
29 kg
city/light terrain
h x w x d - 118 x 68 x 167 cm
mechanics (160 mm)
mechanics/without shock absorber
26"/16"
steel/aluminium
25 Ah IP53
250W - 1 kW
Ø 80 km
25 km/h *
3 A (stronger can be purchased)
61901 CZK without VAT
29 kg
city/light terrain
h x w x d - 118 x 68 x 167 cm
hydraulics (160 mm)
mechanics/without shock absorber
26"/16"
steel/aluminium
30 Ah/35 Ah IP53
250W - 1 kW
Ø 75-85 km
25 km/h *
3 A (stronger can be purchased)
74297 CZK without VAT
45 kg
light terrain
h x w x d - 118 x 75 x 190 cm
Hydraulics (180 mm) HB
oil 100mm/no back. shock absorber
26"/20"
steel/dural
40 Ah IP53
250W - 3 kW
Ø 90 km
70 km/h *
3 A (stronger can be purchased)
98347 CZK without VAT
47 kg
light - medium terrain
h x w x d - 118 x 75 x 201 cm
Hydraulics (180 mm) HB
oil 100mm/no back. shock absorber
26"/20"
steel/dural
Samsung 30Q 33 Ah IP53
250W - 7 kW
Ø 75 km
70 km/h *
3 A (stronger can be purchased)
124793 CZK without VAT
55 kg
medium - heavy terrain
h x w x d - 118 x 75 x 201 cm
MAGURA MT5e / 203 mm
air 120mm/no back. dampers
26" / 20"
steel/dural
